Stainless Hollow Section

Pipe Type: Stainless Steel Square Tube, Stainless Steel rectangular Tube, Square Hollow Section,  Rectangular Hollow Section

Specification:

Square Hollow Section:

          Outside Diameter: 8mm x 8mm – 150mm x 150mm

          Wall Thickness: 0.5mm – 4mm

Rectangular Hollow Section:

           Outside Diameter: 5mm x 20mm – 120mm x 60mm

            Wall Thickness: 0.5mm – 4mm

Standard: ASTM A554,ASTM A249,ASTM A312,DIN11850,JIS G3459,JIS G3448,GB/T12770,GB/T12771

Steel Grades: 304/304L,316/316L,301,202,201,409,410,430

Surface: Pickled, Bright, Matt, Polished, Mirror.

Application: The high quality Stainless steel rectangular pipe / tube is widely used for building, architecture, industry, safeguard, decoration, tools, etc

Send Email Inquiry
Introduction Specification Production process Packaging Inquiry

Introduction

Pipe Type: Stainless Steel Square Tube, Stainless Steel rectangular Tube, Square Hollow Section,  Rectangular Hollow Section

Specification:

Square Hollow Section:

          Outside Diameter: 8mm x 8mm – 150mm x 150mm

          Wall Thickness: 0.5mm – 4mm

Rectangular Hollow Section:

           Outside Diameter: 5mm x 20mm – 120mm x 60mm

            Wall Thickness: 0.5mm – 4mm

Standard: ASTM A554,ASTM A249,ASTM A312,DIN11850,JIS G3459,JIS G3448,GB/T12770,GB/T12771

Steel Grades: 304/304L,316/316L,301,202,201,409,410,430

Surface: Pickled, Bright, Matt, Polished, Mirror.

Application: The high quality Stainless steel rectangular pipe / tube is widely used for building, architecture, industry, safeguard, decoration, tools, etc.

Packing:  Wooden box :packing for Stainless steel rectangular pipe/tube with mirror surface pipe/tube.

Normal size packing:

1.in bundles packing for Stainless steel rectangular pipe/tube without mirror surface.

2.Wooden and pallet packing.Other packing as per customer requirement.

If you have any inquiries and questions, please contact CONTINENTAL STEEL CO.,LTD

at any time. Thanks in advance. Welcome! Email :sales@continental-steel.com

Specification

Size of Stainless Steel Rectangular Tube

Size chart of Stainless Steel Square Pipe



Chemical Composition(%)

Grade

 C Si Mn P S Cr Ni Mo N Cu

201

 ≤0.15 ≤0.75 5.5~7.5 ≤0.060 ≤0.03 16.00~18.00 3.5~5.5 - - 0.08 1.5
202 ≤0.15 ≤1.00 7.5~10.00 ≤0.060 ≤0.03 17.00~19.00

4.0~6.0

 - ≤0.25
301 ≤0.15 ≤1.00 ≤2.00 ≤0.045 ≤0.03 16.00~18.00 6.00~8.00 -
302 ≤0.15 ≤1.00 ≤2.00 ≤0.035 ≤0.03 17.00~19.00 8.00~10.00 -
304 ≤0.07 ≤1.00 ≤2.00 ≤0.045 ≤0.03 18.00~20.00 8.00~10.50 -
304L ≤0.030 ≤1.00 ≤2.00 ≤0.045 ≤0.03 18.00~20.00 9.00~13.00 -
310S ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 24.00~26.00 19.00~22.00 -
316 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 16.00~18.00 10.00~14.00 2.00~3.00
316L ≤0.03 ≤1.00 ≤2.00 ≤0.045 ≤0.03 16.00~18.00 12.00~15.00 2.00~3.00
321 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 17.00~19.00 9.00~13.00 -

430

 ≤0.12 ≤0.75 ≤1.00 ≤0.040 ≤0.03 16.00~18.00



 -
2205 ≤0.03 ≤1.00 ≤2.00 ≤0.030 ≤0.015 22.00~23.00 4.5~6.5 2.5~3.5
2507 ≤0.03 ≤0.08 ≤1.20 ≤0.035 ≤0.015 24.00~26.00 6.00~8.00 3.0~5.0
904L ≤0.02 ≤1.00 ≤2.00 ≤0.045 ≤0.035 19.00~23.00 23.00~28.00 4.0~5.0

1.0~2.0



Production process

Packaging

If you have any inquiries and questions, please contact CONTINENTAL STEEL CO.,LTD. at any time. Thanks in advance. Welcome!
