6063 Aluminum Alloy Introduction

Jun 17, 2024

6063 Aluminum Alloy Introduction

6063 aluminum alloy uses silicon and magnesium as alloying elements. This alloy can be made into complex shapes with smooth surfaces and can be used to make high-quality joinery, corners, nooks, grooves, external corners, rods and noses, and visible elements of architectural decoration. In addition to being used in window and door frames, roofing and signage, 6063 aluminum is also used to make pipes and tubes and furniture applications. The specific mechanical properties of 6063 aluminum vary depending on the state.

6063 Aluminum Alloy Types
UNS A96063, ISO AlMg0.5Si, Aluminum 6063-T6, AA 6063-T6, 6063-O, 6063-T1, 6063-T4, 6063-T5, 6063-T6, 6063-T52, 6063-T53, 6063-T54, 6063-T55, 6063-T832

6063 Aluminum Alloy Chemical Composition
Mg and Si are the main alloying elements of 6063 aluminum.

6063 Aluminum Alloy Mechanical Properties
6063 aluminum is a medium-strength heat-shock-hardened alloy in the AL-Mg-Si system. It has the advantages of excellent processing performance, good weldability, good extrudability, and good corrosion resistance, and is a typical alloy for extrusion processes. Applications that require higher strength generally use 6061 or 6082.

The mechanical properties of 6063 aluminum depend largely on the tempering or heat treatment of the material. The most common tempering conditions for this alloy are:
T5 state: cooled from high temperature and artificially aged.
T6 state: solution heat treated and artificially aged.

6063 chemical composition

Chemical Composition Limits
Weight% Al Si Fe Cu Mn Mg Cr Zn Ti Other Each Others Total
6063 Bal 0.2-0.6 0.35 max 0.10 max 0.10 max 0.45-0.9 0.1 max 0.10 max 0.10 max 0.05 max 0.15 max

6063 Mechanical Properties

Material Diameter or wall thickness (") Tensile Strength (ksi) min Yield Strength (ksi) min Elongation % in 2"
Alloy 6063 <0.125 30 25 8
Alloy 6063 0.125 - 1.00 30 25 10
